IMPACT MOUNT™ SMA CONNECTOR
fiber-optics
Impact Mount™ Technology Concept
The mounting process is accomplished in three steps:
  1. Impact Mount tool dynamically compresses the metal ferrule tip around the fiber
  2. Crimps buffer at the rear of the connector
  3. Polishes end of ferrule in 20 seconds
Note: Additional crimping for Kevlar cables provides further stability and strength.
FEATURES
  • for high power application
  • No epoxy or matching gel
  • Minimum fiber stripping (¼")
  • Crimp rear of connector on buffer
  • Wrap ferrule tip around fiber for quick polishing within seconds
  • Mounted with all-positive-stop mechanical tool
  • Hermetically sealed
  • Field installable and user friendly (two minutes' installation)
APPLICATIONS
• Aerospace
• Military
• Offshore Oil Drilling
• Mining Application
• Optical Sensors
• Medical Application
TECHNICAL SHEETS:
Product Specifications
